 Our new KRATOS SIX 10-pole sensored brushless motors deliver unmatched control that competes with the best of the brushed motors but provides the reliability of brushless power. The result? The fastest-slowest motors money can buy. We are proud to have the first 10-pole inrunners ever produced in the market! These powerhouses offer the best of the best in low speed control and power. The 1950kv is rated from 2s-6s. ESC Type: Castle Mamba X, Monster X, Micro X, and Copperhead. Optional wiring kit not included. Features: * 540-sized sensored brushless motor * 10-pole ​​​​​​kevlar wrapped rotor * High-grade neodymium magnets for optimum power and effiiciency * 12-slot stator * New phase-magnet isolation design * 3.175 pinion shaft * Gold-plated solder tabs, for low resistance / protection against corrosion * Billet CNC one-piece shell with end cap for durability and improved cooling. * Waterproof Technical Specifications: * RPM(kv): 1950 * Construction: 12s/10p * No-load current@7.4v: 1.5A * Operation Voltage: 7.4v-22.2v * Max current: 80A * Max efficiency: 91% * Max working temp: 302f * Dimensions: L52.5 x D35.5 * Weight: 165g * Pinion shaft: L15 x D3.175 Wiring kit is not included: we do have a kit available on the website. : includes 12AWG silicon, high-strand wires, 4mm gold bullet connectors, and sensor wire with gold-plated connectors.



Suggested Castle ESC's:  https://www.3brothersrc.com/product-page/mamba-micro-x2-16-8v-wp-sensored-esc-4-0mm-ro-x2-esc

KRATOS TEN 1950kv 10-pole sensored brushless motor

$139.00Price
  • Motors come with a 1-year warranty against all manufacturer defects. Physical damage, rust, or operation outside the specified range will not be covered under the warranty.



    Warranty claims must be accompanied by proof of purchase from an authorized 3BrothersRC dealer. An individual submitting a warranty claim must ship their motor to 3BrothersRC at their expense. Upon receipt of the motor, 3BrothersRC will repair, or ship a replacement at no additional cost to the customer for standard shipping.

  • "I have never run anything so fast and slow. Top speed is way more than I was expecting. I am speechless on the low speed ability." Joshua, 3800kv



    "I am super excited. This motor is pure power but yet so smooth down low. Crazy great job." Josh, 3800kv
